产品名称:交流充电电缆SS、S90S90、S90U系列
参考标准:GB/T33594-2017、DEKRA K175-2
型 号:EV-SS、EV-RSS、EV-SSPS、EV-RSSPS、EV-S90S90、EV-RS90S90、EV-S90S90PS90、EV-RS90S90PS90、EV-S90U、EV-RS90U、EV-S90S90U、EV-RS90S90U
电缆特性
额定温度 Rated temperature: -40℃~90℃-
额定电压 Rated Voltage: AC 450/750V-
绝缘电阻 Insulation Resistance: ≥0.037MΩ·km at 60℃ comply with CQC1103-215-
燃烧测试 Flame Test: VW-1, test method comply with UL2556-
最小弯曲半径 Min Bending Radius: ≥6*OD-
耐压 Dielectric Voltage: 2.5kVac/15min. No breakdown-
低温冲击 Low temperature impact: -40℃, no cracks-
热冲击 Hot Shock: 150℃/1h, no cracks-
耐油 Oil Resistance: IRM902, IRM903, gasoline 20h OD variation≤15% no cracks-
抗挤压 Crush Resistance: Sq≤4, crush force≥4kN; 4≤Sq≤35, crush force≥11kN-
耐酸碱 Resistance to Acid and alkali: 168h, tensile strength variation ≤30%; Elongation≥100%-
环保要求 Environmental Requirements: Compliant with RoHS2.0 and REACH-
结构截面:
