产品名称:EN&IEC及欧洲机构标准充电电缆
参考标准:EN 50620:2017、IEC62893-3:2017、DEKRA K175
型 号:H05BZ5-F 62893IEC121、H07BZ5-F 62893IEC123
电缆特性
额定温度 Rated temperature: -40℃~90℃-
额定电压 Rated Voltage: AC 300/500V, 450/750V; DC 1000V-
燃烧测试 Flame Test: Testing method according to EN 60332-1-2-
最小弯曲半径 Min Bending Radius: ≥6*OD-
耐压 Dielectric Voltage: 2.5kV AC for main core, 2.0kV AC for CC/CP-
低温冲击 Low temperature impact: -40℃, no cracks-
热冲击 Hot Shock: 150℃/1h, no cracks-
耐油 Oil Resistance: IRM902, 100℃/168h, tensile strength variation <±40%, elongation variation <±30%-
抗挤压 Crush Resistance: Sq≤4, crush force≥4kN; 4≤Sq≤35, crush force≥11kN-
耐酸碱 Resistance to Acid and alkali: 168h, tensile strength variation ≤30%; Elongation≥100%-
环保要求 Environmental Requirements: Compliant with RoHS2.0 and REACH-
结构截面:
