产品名称:充电电缆
参考标准:UL62
型 号:600V or 1000V EVE(TPE) EVT(PVC)、300V EVJE(TPE) EVJT(PVC)
电缆特性
额定温度 Rated temperature: -40℃~105℃-
额定电压 Rated Voltage: 300V, 600V, 1000V-
燃烧测试 Flame Test: VW-1, test method comply with UL2556-
最小弯曲半径 Min Bending Radius: ≥6*OD-
耐压 Dielectric Voltage: 1.5kVac/1min. No breakdown. Test method comply with UL2556-
低温弯曲 Cold Bending: -40℃/4h. No cracks. Test method comply with UL2556-
热冲击 Hot Shock: 150℃/1h. No cracks. Test method comply with UL2556-
耐油 Oil Resistance: IRM902, 60℃/168h. Tensile and elongation variation ≤30%-
耐碾压 Crush Resistance: S≤12AWG 4.45kN, 12AWG<S≤2AWG 11.1kN, 2AWG<S 15.6kN-
耐气候 Weather Resistance: 720h in a xenon arc weatherometer, No cracks-
环保要求 Environmental Requirements: Compliant with RoHS2.0 and REACH-
结构截面:
